PICkit? 2 Debug Express

Summary

PICkit? 2 Debug Express allows in-circuit debugging on

selected PIC? microcontrollers. In-circuit debugging allows

the designer to run, halt and single step the program while

the PIC microcontroller is embedded in the hardware. Once

halted, the ?le registers may be examined and modi?ed. This

greatly assists the designer in debugging the ?rmware and

hardware together.

The PICkit 2 Debug Express is a low-cost development

kit with an easy to use interface for debug as well as

programming. It comes complete with a development

board that contains Microchip’s 44-pin PIC16F917

Flash microcontroller. This starter kit is designed to

help developers get up to speed quickly using PIC?

microcontrollers and provides everything needed to program,

evaluate and develop applications. Instructions are provided

in a series of twelve lessons that cover I/O, Interrupts,

A/D Converters, Data Tables and Timers with an additional

lesson covering debugging features. All source code ?les for

the lessons are furnished.

Microchip’s powerful MPLAB? Integrated Development

Environment (IDE) is a seamless, integrated software

development environment that includes a MPASM? macro

assembler, MPLAB SIM software simulator with symbolic

debugger, color-coded source editor, project manager with

high-level language debugging and concurrent support for

development tools, including low-cost in-circuit debuggers,

full-featured real-time emulators and programmers. The

consistent and easy-to-use graphic user interface of

the MPLAB desktop allows for rapid switching between

development, debugging and programming modes within a

project.

PICkit 2 Debug Express offers basic MPLAB ICD 2 style

debugging integrated with MPLAB IDE and offers the

following functions:

? Programming

? Reset

? Run

? Halt

? Single Step

? Animate

? Single breakpoint

? Examine/Change File Registers

NEW

Features

PICkit 2 Debug Express (DV164121) bundles the

PICkit 2 Device Programmer with a 44-pin demo board.

The board includes a PIC16F917 TQFP pre-soldered

device and a generous surface mount prototyping area.

Tutorials in the User’s Guide demonstrate the debugging

features implemented.

Users that already have a PICkit 2 Device Programmer

(PG164120) may wish to purchase only the new 44-pin

demo board (DM164120-2) for evaluation.

? 44-pin Demo Board with PIC16F917 Mid Range

PIC microcontroller

? Easy to use Windows? programming of select

Flash based PIC microcontrollers

? Twelve sequential lessons written in Assembly

demonstrate how to use Microchip’s 20-pin Flash

family of microcontrollers.

? Lesson included for the Debug Features (PIC16F917)

? Technical documentation CD including:

– PICkit 2 User’s Guide

– Low Pin Count Demo Board User’s Guide

– Tips ‘n Tricks Booklets

– Selected Application Notes

? FREE! Microchip’s MPLAB IDE software for a complete

code development environment

? FREE! HI-TECH PICC? LITE C Compiler (contained on

the MPLAB CD)

? FREE! CCS PCB Baseline C Compiler Installed with

MPLAB 7.41 or greater

Microchip Technology Incorporated
